Armoured Cable

LT XLPE / PVC insulated Copper & Aluminum Armoured cables

Armoured cables are electrical cable with metallic protection over insulated conductors. For additional protection the conductors are insulated with plastic layer surrounded by metallic cover. The metallic layer provides mechanical strength against any sort of damage. The armoured layer can be Copper, Aluminum or Steel. These cables are used in power supply for large application.

Insulation: 1.1 kv grade Armoured cables are available with XLPE and PVC insulation. Manufactured as per IS 7098 Part 1 & IS 1554.

Conductor: All Conductors confirm to IS:8130. Power cables are made from electrolytic grade aluminum and for control cables high conductivity annealed copper.

Types of Armoured Cables:

  • Copper Armoured Cable
  • Aluminium Armoured Cable
  • Flat Steel Strip Armoured Cable
  • Steel Wire Armoured Cable (SWA)

Applications of Armoured Cable:

  • Power Transmission
  • Underground cable system
  • Outdoor & Indoor applications

LT XLPE Cable with Copper & Aluminum Conductors
Nominal conductor size (Sq. mm) Minimum No. of Wires DC reistance @ 20°c (Ohm/Km) AC reistance @ 90°c (Ohm/Km)
Non Compacted Compacted
Copper Aluminum Copper Aluminum Copper Aluminum Copper Aluminum
1.5 3 3 - - 12.1 18.1 15.5 23.17
2.5 3 3 - - 7.41 12.1 9.48 15.5
4 7 3 - - 4.61 7.41 5.9 9.48
6 7 3 - - 3.08 4.61 3.94 5.9
10 7 7 6 - 1.83 3.08 2.34 3.94
16 7 7 6 6 1.15 1.91 1.47 2.44
25 7 7 6 6 0.727 1.2 0.93 1.54
35 7 7 6 6 0.524 0.868 0.671 1.11
50 19 19 6 6 0.387 0.641 0.495 0.82
70 19 19 12 12 0.268 0.443 0.343 0.567
95 19 19 15 15 0.193 0.32 0.247 0.41
120 37 37 18 15 0.153 0.253 0.196 0.324
150 37 37 18 15 0.124 0.206 0.159 0.264
185 37 37 30 30 0.0991 0.164 0.127 0.21
240 61 37 34 30 0.0754 0.125 0.0965 0.16
300 61 61 34 30 0.0601 0.1 0.0769 0.128
400 61 61 53 53 0.047 0.0778 0.0602 0.1
500 61 61 53 53 0.0366 0.0605 0.0468 0.0774
630 61 91 53 53 0.0283 0.0469 0.0362 0.06
800 61 91 53 53 0.0221 0.0367 0.0283 0.047

HT XLPE Cable with Copper & Aluminum Conductors
Nominal conductor size (Sq. mm) Minimum No. of Wires Max DC reistance @ 20°c DC reistance @ 20°c (Ohm/Km) AC reistance @ 90°c (Ohm/Km) Current rating (K.Amps)
Copper Aluminum Copper Aluminum Copper Aluminum Copper Aluminum
25 6 6 0.727 1.2 0.927 1.54 3.58 2.36
35 6 6 0.524 0.868 0.668 1.11 5.01 3.31
50 6 6 0.387 0.641 0.494 0.822 7.15 4.72
70 12 12 0.268 0.443 0.342 0.568 10.02 6.61
95 15 15 0.193 0.32 0.247 0.411 13.59 8.98
120 18 15 0.153 0.253 0.196 0.325 17.17 11.34
150 18 15 0.124 0.206 0.159 0.265 21.46 14.17
185 30 30 0.0991 0.164 0.128 0.211 26.47 17.48
240 34 30 0.0754 0.125 0.0982 0.161 34.34 22.68
300 34 30 0.0601 0.1 0.0792 0.13 42.93 28.35
400 53 53 0.047 0.0778 0.0632 0.102 57.23 37.79
500 53 53 0.0366 0.0605 0.0509 0.0801 71.54 47.24
630 53 53 0.0283 0.0469 0.0414 0.0634 90.14 59.52
800 53 53 0.0221 0.0367 0.0349 0.0513 114.47 75.59
1000 53 53 0.0176 0.0291 0.0306 0.0426 143.08 94.48
